Why Use ThermaCork Standard

Insulation in Construction?



It's the Natural Choice

It's a 100% natural product that supports cork forests, which in turn host a wide range of plants and animals, support local economies, and help reverse planetary damage by absorbing carbon dioxide in the atmosphere and avoiding soil desertification. Once produced, the finished product actually has a negative carbon footprint. The process of production, from harvest to production, is one of the most sustainable sustainable business practices on Earth.

It's an Energy Saver

Cork insulation will drastically reduce energy consumption, and its energy saving qualities will last decades, far longer than most choices. This is due to cork's high insulating range, stability, and its reduction of thermal bridging.


Superior Qualities

Cork is incredibly stable and can cope with major thermal variations, between (-) 292 degrees F to (+) 248 degrees F. It's hypoallergenic and free of all domestic toxins, all while preventing mold by its ability to "dry through" layers. It's high on the insulating range (R-4 per inch), reduces thermal bridging, and its thermal resistance does not decrease over time like man-made foam. It has excellent sound isolation, is dimensionally stable, and resistant to compression.


Technical Characteristics

Thermal Conductivity: 0.036-0.38 W/mk for a declared value of EU label 0.04 W/mk

Thermal Resistance: R-3.6 to R-4.2/inch, declared value for EU label of R-4/inch

Density: 7.0-7.5 lbs/ft3 or 100-120 Kg/m3

Perpendicular Face Resistance:60 Kpa or 8.7 PSI

Compression Resistance: 10% at 100u Kpa (14.5 PSI)

Permeability:

  • 1 1/2" thickness:2.15 US perms
  • 2" thickness: 2.04 US perms
  • 4" thickness:1.26 US perms

Maximum Moisture Content: 8%, with water absorption declared at 0.5 kg/m3

Longitude Tolerance: +/-0.1 to 0.2" or +/-3 to 5 mm

Thickness Tolerance: 0.04 to 0.1" or +/-1 to 2 mm

Fire Resistance: Euro Class "E"



Check out some of the Application schematics we've put together.



Standard Grade ThermaCork Insulation



Size     Item              Standard                                                                                              Ft2/Pack

1/2"      TC 12-24      12mm x 1000 x 500mm (1/2" x 39" x 19 5/8") 24boards/pack          128.00

3/4"     TC 20-15      20 x 1000 x 500mm       (3/4" x 39" x 19 5/8"), 15 boards/pack          80.7

1"         TC 25-12      25 x 1000 x 500 mm      (1" x 39" x 19 5/8"), 12 boards/pack            64.56

1 1/2"   TC 40-8        40 x 1000 x 500mm      (1 1/2" x 39" x 19 5/8"), 8 boards/pack        43.04

2"       TC 50-6        50 x 1000 x 500mm      (2" x 39" x 19 5/8"), 6 boards/pack                 32.28

3"       TC 75-4        75 x 1000 x 500 mm      (3" x 39" x 19 5/8"), 4 boards/pack                21.52

4"       TC 100-3      100 x 1000 x 500mm     (3" x 39" x 19 5/8"), 3 boards/pack                16.14

6"       TC 150-21     50 x 1000 x 500mm      (6" x 39" x 19 5/8"), 2 boards/pack                10.76

8"       TC 200-2     200 x 1000 x 500mm    (8" x 39" x 19 5/8"), 2 boards/pack                  10.76

12"      TC 300-1      300 x 1000 x 500mm    (12" x 39" x 19 5/8"), 1 board/pack                5.38
